TM1PB 1/4' Phone Switch Plug, Male, Nickel Plated, Black Shell

TM1PB 1/4" Phone Switch Plug, Male, Nickel Plated, Black Shell

$0.00

Switch Plug for Instruments

PART NUMBER: TM1PB

Datasheet:

Positions: 1
Finish: Black
Contact Plating: Nickel
IP Rating: IP40
Current Carrying Capacity: 10A (depends on mating connector and cable)
Termination: Solder
Max Wire Gauge: 18AWG -1mmÂ²
Flammability Rating: UL94V-0 or UL94-HB
Environmental: Complies with EU RoHS 2 Directive 2011/65/EU
Typical Contact Resistance: Depends on mating connector
Insulation Resistance: > 2GΩ/ >1GΩ after Damp Heat Test
Operating Temperature: -25°C to +75°C (-13°F to 167°F)
Insertion and Withdrawal Force: > 10N - < 30N
Typical Cable Retention Force: 22kg to 44kg (50lb to 100lb) - Dependent on cable material and diameter.
Cable OD Range: 3mm to 6mm (0.118â€ to 0.236â€)
Mating Cycles: 1000
Housing Material: Diecast Zinc Alloy EZDA No.3
Application(s): Audio & Lighting
