  6. T 3302 550 - M16 Front mounting male receptacle with ring nut. 4 contacts, sold separately Contacts sold separately.
T 3302 550 - M16 Front mounting male receptacle with ring nut. 4 contacts, sold separately Contacts sold separately.
T 3302 550 - M16 Front mounting male receptacle with ring nut. 4 contacts, sold separately Contacts sold separately.

T 3302 550 - M16 Front mounting male receptacle with ring nut. 4 contacts, sold separately Contacts sold separately.

$0.00
Male Receptacle
PART NUMBER: T3302550
Datasheet: datasheet Download datasheet View / Download

SPECIFICATIONS:

  • Contacts: 4
  • Current Rating: 10A
  • Termination: Crimp
  • Locking: Screw
  • Insert: Thermoplastic
  • Wire Gauge: 0.09 - 1.0mm² (28-18 AWG)
  • Housing: Zinc Die Cast, Nickel Plated
  • Protection: IP40
  • Insertion/Withdrawal Force: 30 N
  • Insulation Resistance: > 10(10) Ω
  • Rated Voltage IEC 60664-1: 300V
  • Rated Voltage per UL 1977: 250V
  • Rated Impulse Withstanding Voltage IEC 60664-1: 1500V
  • Contact Resistance: < 5mΩ
  • Mount: Front
  • Operating Temperature: -40²C to +100²C
  • Mating Part(s): T3303550,T3303150,T3301551,T3301554
  • Size: M16
Front mounting male receptacle with ring nut (hex nut available upon request). 4 contacts, sold separately. Termination: solder or crimp.
