  6. T 3262 420 - M16 Rear mounting male receptacle with ring nut. 3 contacts, silver plated Contacts included.
T 3262 420 - M16 Rear mounting male receptacle with ring nut. 3 contacts, silver plated Contacts included.
T 3262 420 - M16 Rear mounting male receptacle with ring nut. 3 contacts, silver plated Contacts included.

T 3262 420 - M16 Rear mounting male receptacle with ring nut. 3 contacts, silver plated Contacts included.

$0.00
Male Receptacle
PART NUMBER: T3262420
Datasheet: datasheet Download datasheet View / Download

SPECIFICATIONS:

  • Contacts: 3
  • Contact Resistance: < 5mΩ
  • Insulation Resistance: > 10(10) Ω
  • Lifetime: > 500 mating cycles
  • Wire Gauge: 0.5 mm² (20 AWG)
  • Pin length: 14.5mm from flange
  • Insertion/Withdrawal Force: 25 N
  • Operating Temperature: -40°C to +100°C
  • Current Rating: 10A
  • Housing: Die cast, nickel plated
  • Protection: IP40
  • Mount: Rear
  • Locking: Screw
  • Contact Plating: Silver
  • Termination: Solder
  • Insert: Thermoplastic
  • Rated Voltage IEC 60664-1: 300V
  • Rated Voltage per UL 1977: 250V
  • Rated Impulse Withstanding Voltage IEC 60664-1: 1500V
  • Mating Part(s): T3263320,T3263330,T3263420,T3263430
  • Size: M16
Rear mounting male receptacle with ring nut (hex nut available upon request). Pin length of 14.5mm from flange. Contacts included.
