  6. T 3260 002 - M16 Male straight cable connector with internal strain relief and metal locking ring. 3 contacts, silver plated, 6 - 8mm cable diameter Contacts included. Comparable to PN# 99-2005-02-03, 09-0005-02-03
T 3260 002 - M16 Male straight cable connector with internal strain relief and metal locking ring. 3 contacts, silver plated, 6 - 8mm cable diameter Contacts included. Comparable to PN# 99-2005-02-03, 09-0005-02-03
T 3260 002 - M16 Male straight cable connector with internal strain relief and metal locking ring. 3 contacts, silver plated, 6 - 8mm cable diameter Contacts included. Comparable to PN# 99-2005-02-03, 09-0005-02-03

T 3260 002 - M16 Male straight cable connector with internal strain relief and metal locking ring. 3 contacts, silver plated, 6 - 8mm cable diameter Contacts included. Comparable to PN# 99-2005-02-03, 09-0005-02-03

$0.00
Male Cable Connector
PART NUMBER: T3260002
Datasheet: datasheet Download datasheet View / Download

SPECIFICATIONS:

  • Contacts: 3
  • Contact Resistance: < 5mΩ
  • Insulation Resistance: > 10(10) Ω
  • Lifetime: > 500 mating cycles
  • Wire Gauge: 0.5 mm² (20 AWG)
  • Insertion/Withdrawal Force: 25 N
  • Operating Temperature: -40°C to +100°C
  • Current Rating: 10A
  • Cable Diameter: 6 - 8mm
  • Housing: Die cast, nickel plated
  • Protection: IP40
  • Locking: Screw
  • Contact Plating: Silver
  • Termination: Solder
  • Version: Straight
  • Insert: Thermoplastic
  • Rated Voltage IEC 60664-1: 300V
  • Rated Voltage per UL 1977: 250V
  • Rated Impulse Withstanding Voltage IEC 60664-1: 1500V
  • Mating Part(s): T3261002,T3263000,T3263300,T3263100
  • Size: M16
Male cable connector with internal strain relief and metal locking ring. Screw locking according to IEC 61076-2-106. Contacts included.
