  6. C091 51G008 150 2 - M16 PCB mounting female receptacle with ring nut. 8 contacts, silver plated. Contacts included.
C091 51G008 150 2 - M16 PCB mounting female receptacle with ring nut. 8 contacts, silver plated. Contacts included.
C091 51G008 150 2 - M16 PCB mounting female receptacle with ring nut. 8 contacts, silver plated. Contacts included.

C091 51G008 150 2 - M16 PCB mounting female receptacle with ring nut. 8 contacts, silver plated. Contacts included.

$0.00
Female Receptacle
PART NUMBER: C09151G0081502
Datasheet: datasheet Download datasheet View / Download    3D Model: datasheet Download 3D Model View/Download

SPECIFICATIONS:

  • Contacts: 8
  • Current Rating: 7A
  • Termination: Solder
  • Locking: Screw
  • Contact Plating: Silver
  • Insert: Thermoplastic
  • Version: Right angled
  • Wire Gauge: 0.5 mm² (20 AWG)
  • Housing: Zinc Die Cast, Nickel Plated
  • Protection: IP67/ 65 (in mated condition)
  • Insertion/Withdrawal Force: 60 N
  • Insulation Resistance: > 10(10) Ω
  • Rated Voltage IEC 60664-1: 100V
  • Rated Voltage per UL 1977: 250V
  • Rated Impulse Withstanding Voltage IEC 60664-1: 1200V
  • Contact Resistance: < 5mΩ
  • Mount: PCB with board lock
  • Operating Temperature: -40°C to +100°C
  • Lifetime: >500 mating cycles
  • Size: M16
PCB mounting female receptacle with ring nut (hex nut available upon request). Contacts included.
