  6. C091 31W105 100 2 - M16 Front mounting male metal receptacle with O-ring seal and ring nut mount. 5 contacts, silver plated. Contacts included. Comparable to PN# 09-0119-00-05
C091 31W105 100 2 - M16 Front mounting male metal receptacle with O-ring seal and ring nut mount. 5 contacts, silver plated. Contacts included. Comparable to PN# 09-0119-00-05
C091 31W105 100 2 - M16 Front mounting male metal receptacle with O-ring seal and ring nut mount. 5 contacts, silver plated. Contacts included. Comparable to PN# 09-0119-00-05

C091 31W105 100 2 - M16 Front mounting male metal receptacle with O-ring seal and ring nut mount. 5 contacts, silver plated. Contacts included. Comparable to PN# 09-0119-00-05

$0.00
Male Receptacle
PART NUMBER: C09131W1051002
Datasheet: datasheet Download datasheet View / Download    3D Model: datasheet Download 3D Model View/Download

SPECIFICATIONS:

  • Contacts: 5S (stereo)
  • Current Rating: 7A
  • Termination: Solder
  • Locking: Screw
  • Contact Plating: Silver
  • Insert: Thermoplastic
  • Version: Ring Nut, Metal
  • Wire Gauge: 0.5 mm² (20 AWG)
  • Housing: Zinc Die Cast, Nickel Plated
  • Protection: IP67/ 65 (in mated condition)
  • Insertion/Withdrawal Force: 35 N
  • Insulation Resistance: > 10(10) Ω
  • Rated Voltage IEC 60664-1: 100V
  • Rated Voltage per UL 1977: 250V
  • Rated Impulse Withstanding Voltage IEC 60664-1: 1200V
  • Contact Resistance: < 5mΩ
  • Gasket: Neoprene
  • Mount: Front mount w/ring nut
  • Operating Temperature: -40°C to +100°C
  • Lifetime: >500 mating cycles
  • Mating Part(s): C09131N1051002,C09131G1051002,C09131D1051002,C09131F1051002
  • Size: M16
Front mounting male metal receptacle with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included. Contact arrangement according to DIN EN 6107. Replaces C091 11W105 000 2.
