AP-6-11 6 Pole Female Loudspeaker Cable Connector, Thermoplastic Shell, Machined Contacts, Black Finish
AP-6-11 6 Pole Female Loudspeaker Cable Connector, Thermoplastic Shell, Machined Contacts, Black Finish

AP-6-11 6 Pole Female Loudspeaker Cable Connector, Thermoplastic Shell, Machined Contacts, Black Finish

$0.00
Female Loudspeaker Cable Connector
PART NUMBER: AP-6-11
Datasheet: datasheet Download datasheet View / Download

SPECIFICATIONS:

  • Positions: 6
  • Gender: Female
  • Current Carrying Capacity: 20A
  • Housing Material: Modified PPE Resin
  • Finish: Black
  • Contact Type: Machined
  • IP Rating: IP40
  • Termination: Solder
  • Max Wire Gauge: 12AWG
  • Operating Temperature: -25°C to +75°C (-13°F to +167°F)
  • Mating Cycles: 1000
  • Flammability Rating: UL94V-0
  • Environmental: Complies with EU RoHS 2 Directive 2011/65/EU
  • Application(s): Audio & Lighting
6 Pole Female Loudspeaker Cable Connector, Thermoplastic Shell, Machined Contacts, Black Finish
