2CMA105086R1000 2P+E Female Industrial Switched Mechanical Interlocked Socket Outlet, 20A, 277V, 5H, IP67. Replaces Part# ABB320MI5WN
2CMA105086R1000 2P+E Female Industrial Switched Mechanical Interlocked Socket Outlet, 20A, 277V, 5H, IP67. Replaces Part# ABB320MI5WN

2CMA105086R1000 2P+E Female Industrial Switched Mechanical Interlocked Socket Outlet, 20A, 277V, 5H, IP67. Replaces Part# ABB320MI5WN

$0.00
Outlet
PART NUMBER: 2CMA105086R1000
Datasheet: datasheet Download datasheet View / Download

SPECIFICATIONS:

  • Number of Poles: 3
  • Contacts: 2P+E
  • Contacts Included?: No
  • Clock Position: 5Hour
  • Current Rating: 20
  • IP Protection Rating: IP67
  • Operating Temperature: -25°C to 40°C
  • Cable Cross Section: 1.5 - 4 mm²
  • Housing Material: Thermoplastic (PBT)
  • Voltage Rating: 277V
  • Frequency: 50 hertz|60 hertz
  • Color Coding: Grey
  • Shape: Circular
  • RoHS Status: Following EU Directive 2011/65/EU
  • International Electrical Standards: UL 1682, 1686 / CSA C22.2 No. 182.1-13, IEC 60309
2P+E Female Industrial Switched Mechanical Interlocked Socket Outlet, 20A, 277V, 5H, IP67. Replaces Part# ABB320MI5WN
